Pin Stamp Marking
An economical, adaptable process that's easy to implement, offering high speed and power in marking.
Contact us Contact usPinstamp
We are exclusive distributors in Texas of Telesis pinstamp marking and engraving systems. We offer a wide range of solutions for industrial identification and traceability, ensuring exceptional durability and unmatched service.
Types of PinStamp Marking Machines
Non-portable Pinstamp Marking Systems
Telesis BM200 Fixed Dot Peen System
Electric Equipment Marking Window: 4 x 4" Simple programming for immediate use and low cost. Ideal for low-volume applications and precise marking.
Telesis TMM5100/470 Dot Peen Engraving System
Pneumatic Equipment Marking Window: 0.625 x 4.5" Multi-point equipment with a configurable cartridge for marking in hard-to-reach areas.
Telesis Pinstamp Marking System TMP3200/470E Dot Peen
Pneumatic Equipment Marking Window: 4 x 6" Large marking window. Recommended for inline or manual feed operations.
Telesis TMP6100 Dot Peen Marker
Pneumatic Equipment. Marking Window: 6 x 12". The largest marking window available on the market, ideal for larger markings.
Telesis TMP7000 Fixed Dot Peen System
Pneumatic Equipment Marking Window: 4 x 6" Robust design with deep marking capability.
Telesis TMM5400 Dot Peen Engraving Machine
Pneumatic Equipment Marking Window: 0.5 x 3.78" Multi-pin equipment with marking speed of up to 16 characters per second.
Telesis BM320 Pinstamp Marking System
Electric Equipment Marking Window: 4 x 6" Simple programming for immediate use, with the option to control via visual software.
Telesis TMM4250 Fixed Dot Peen System
Pneumatic Equipment Marking Window: 0.5 x 2" IP55 protection level, ideal for harsh environments.
Telesis TMM7200/420 Pinstamp Marking Machine
Pneumatic Equipment Configurable with up to 21 points to improve marking cycle efficiency.
Telesis Pinstamp TMP1700/470 and TMP1700/470E Dot Peen System
Electric Equipment Marking Window: 1.5" x 2.5" The most advanced marker in the industry, with high precision and speed.
Portable Pinstamp Marking Systems
Telesis Pinstamp Marking System TMP4210/470F, TMP4210/470H
Pneumatic Equipment Marking Window: 0.5 x 2" Compact design for both portable and fixed applications.
Telesis Pinstamp Marking Machine TMM4200/470 Dot Peen
Pneumatic Equipment Marking Window: 0.5 x 2" Ergonomic and compact design, multi-point for higher marking speed.
Telesis Pinstamp Marking System TMM4215/470F, TMM4215/470H
Pneumatic Equipment Marking Window: 0.5 x 4" Portable applications with a large marking window. Option for fixed mounting.
Telesis Pinstamp Benchmark BM200/470, BM320/470, BM320M/470, BM460/470, BM460FP Dot Peen Marker
Electric Equipment Marking Window: 1 x 4" Fully programmable with low cost, ideal for marking large or heavy parts.
Telesis Pinstamp Marking Machine TMP4500E/470
Electric Equipment Marking Window: 1 x 4" Electromechanical pin drive, no air required. Offers good marking depth capability.
Challenges solved by PinStamp Marking Technology
- Piece identification is often delayed until the final production phase. PinStamp technology enables flexible, precise marking at any stage, ensuring full traceability throughout the process.
- Limited Space or Time at Workstations In some workstations, limited space or time makes additional marking processes challenging. PinStamp´s compact, portable systems integrate seamlessly into tight spaces or fast-paced workflows, without compromising marking quality.
- Fragile or Soft Materials Materials may be too fragile or soft to withstand marking until they reach their final state. Pinstamp’s adaptable marking systems can handle a variety of materials with different levels of toughness, ensuring effective marking even on delicate surfaces.
- High Product Temperature When products are too hot to allow for marking during production, Pinstamp technology offers solutions that can operate at high temperatures, ensuring traceability without interruption.
- Shape or Size Limitations Marking products with irregular shapes or sizes can be challenging for traditional methods. Pinstamp systems are highly flexible and can handle a wide range of shapes and sizes, ensuring that each piece is accurately marked.
- Need for Changing or Adjusting Marked Numbers In situations where numbers or markings need to be changed or adjusted, Pinstamp offers programmable systems that make it easy to update markings, ensuring that the identification remains relevant and accurate throughout production.
Request a Demo
Let us showcase our expertise in industrial marking systems and why we are your best choice. See firsthand the efficiency, precision, and versatility of our solutions.
Request a DemoLearn More About Pinstamp Marking
What is it?
What is Pinstamp Marking Technology?
Dot Peen technology involves creating a matrix of dots to generate high-precision markings such as symbols, Datamatrix codes, alphanumeric data (serial numbers, names, dates), logos, etc.
Our Telesis Pinstamp marking machines offer a variety of tips, differing in mass and conicity, to provide different engraving qualities. Pinstamp marking allows you to avoid material removal in the process, resulting in a clean, environmentally friendly marking without the creation of annoying metal shavings.
This technology is extremely powerful, versatile, and cost-effective, as it requires minimal maintenance and consumables for operation. Pinstamp marking can be applied to all types of metals, such as aluminum, copper, steel, alloys, etc., for traceability, identification in processes, and branding.
In addition to ensuring greater durability, it does not damage or erode the marked surfaces and resists exposure to chemicals, oxidation, and weathering during its useful life.
Advantages
Advantages of Pinstamp Marking vs. Other Techniques
Some benefits of this technology include:
- - Lower cost compared to other technologies
- - Marks remain readable even after painting processes
- - Ability to create logos, letters, and Datamatrix codes
- - Simple programming with intuitive handling
- - Adjustable marking depth on all types of materials and shapes
- - High-quality and high-speed coding
- - Low maintenance and minimal consumable usage
- - Autonomous operation without the need for a PC
- - Capable of being implemented in automated processes
- - Easy to transport and install
- - Less material waste and shorter cycles
Applications of Pinstamp Marking
What processes/applications are ideal for choosing the Pinstamp marking solution?
Peen marking is ideal for the following applications and tasks:
- - Suitable for all types of work environments and surfaces.
- - DPM (Direct Part Marking) applications.
- - Permanent marking on various metals: copper, aluminum, steel, alloys, etc.
- - Traceability and control of products/pieces in processes.
- - Available as individual units or integrable into production lines.
- - Tool identification.
- - Long-lasting markings resistant to chemical processes, corrosion, painting, etc.
- - Coding on large parts such as tubes, plates, bars, etc.
Industries
Which industries benefit most from pinstamp marking?
Our Dot Peen marking systems are highly sought after in numerous sectors of heavy industry:
- - Aerospace / Aircraft manufacturers and suppliers
- - Automotive (Manufacturers and OEMs)
- - Communications
- - Construction
- - Railway construction
- - Electronics
- - Recreational equipment (ATV manufacturers, etc.)
- - Machinery manufacturers
- - Raw material manufacturers (steel bars, tubes, plates, and large parts, etc.)
- - Motorcycle manufacturers
- - Heavy machinery
- - Marine, military, and defense
- - Metallurgy
- - Oil, energy, and gas (pumps, valves, etc.)
- - Industrial products (manufacturers of bearings, cutting machines, tools, etc.)
- - Don’t see your industry? We want to learn about your project?
The Impact of Industrial Traceability in Modern Processes
Pinstamp marking, although reliable and versatile, can face challenges arising from equipment selection, configuration, or inadequate maintenance. Some of the most common mistakes include:
- Buying the wrong equipment: Many Pinstamp marking machines do not offer the same performance, which may lead to variations in ease of use, efficiency, consistency in marking quality, or portability of the equipment.
- Choosing a Pinstamp marking machine with an undesired pattern or depth: There are various Dot Peen marking machines, some that create deeper holes and others that create more superficial markings in a fluid line.
- Incorrect configuration of parameters: Incorrect depth or speed settings on the pinstamp marking equipment can result in illegible or inconsistent marks.
- Incompatible materials: Manufacturers recommend using pinstamp marking machines exclusively on materials that can withstand the mechanical impact generated by the machine.
- Lack of regular maintenance: Ignoring the manufacturer's recommendations affects the performance of the Dot Peen engraving system. Regular cleanings, lubrications, and replacement of the stylus increase the system's lifespan.
Guide to Pinstamp Marking
Dot Peen marking, also known as micro-engraving or Pinstamp marking, is a reliable and versatile industrial technology for permanently part and product identification.
How does Pinstamp marking work?
The Dot Peen process uses a metal striker, powered either electromagnetically or pneumatically, which generates a series of controlled impacts to form characters, logos, or tracking codes directly on the surface of the parts being manufactured by a company.
This method is particularly useful for materials ranging from soft plastics to hardened steels with a hardness of up to 60 Rc.
Guide to Pinstamp Marking
- Durability: The marks are resistant to abrasion, corrosion, and high temperatures.
- Versatility: Compatible with a wide range of materials and shapes, including curved and irregular surfaces..
- Efficiency: Requires low maintenance, especially in advanced models with X/Y pinion and rack platforms.
- Sustainability: Some systems eliminate the need for compressed air, reducing operational costs and environmental impact.
Key Features of Pinstamp Marking Systems
- Precision and Depth: Some machines are capable of making deep and clear marks, even in challenging industrial conditions.
- Portability: Portable models are ideal for field applications.
- Connectivity: Advanced controllers with USB, Ethernet ports, and touch screens make it easy to integrate into production lines.
Factors to Consider When Purchasing a Pinstamp Marking Machine
Selecting the right Pinstamp marking machine requires evaluating several key aspects:
- Specific Requirements: Identify whether you need a fixed system or a portable Dot Peen machine for your workspace.
- Material Compatibility: Ensure the pinstamp marking machine can effectively work with the materials you use.
- Ease of Integration: Make sure the engraving system can integrate smoothly with your existing production line.
Choosing a Pinstamp marking system ensures that your Dot Peen marking needs are met with precision and efficiency, helping businesses maintain high traceability standards.
PinStamp Marking Systems Service Model
As part of our value delivery, we provide expert industry advice to help you find the products that best fit your processes.
1
Detection of the Need
2
Specialized Team Consultation
3
Solution Presentation and Testing
4
Project Implementation
5
Ongoing Support
Frequently Asked Questions about Pinstamp Marking
What is pinstamp marking?
Dot Peen Marking also known as micropoint or micropunching, is a mechanical technology used for marking. It works by deforming the surface of the material using a tool that vibrates at high frequency and speed.
What is a pinstamp marking machine?
An industrial marking system refers to a method that allows each manufactured part to be uniquely identified in any production process. The use of this system ensures that all produced parts can be traced 100% throughout the manufacturing process.
What is industrial marking?
Industrial marking involves labeling products with information such as text, codes, and logos to manage product or part tracking systems. There are various technologies and methods used to carry out the industrial marking process.
